Quartz powder, also known as silica micro powder, is primarily composed of high-purity silicon dioxide (Si O₂). It features high hardness (Mohs hardness of approximately 7), excellent chemical stability, good electrical insulation, high whiteness, and resistance to acids, alkalis, and ultraviolet light. As a core functional filler in coating systems, the proper selection of particle size and dosage can significantly enhance film hardness, abrasion resistance, weatherability, and application performance, while also optimizing formulation costs. The following sections detail its main functions, typical industry applications, and usage recommendations.
1. Enhancing Film Hardness and Abrasion Resistance
Due to its high hardness, quartz powder markedly improves the surface hardness, scratch resistance, and abrasion resistance of the coating film. It is particularly suitable for coatings subjected to frequent friction, impact, or cleaning, effectively extending service life.
2. Improving Weatherability and Anti-Aging Performance
With its chemical stability and resistance to acids, alkalis, and UV radiation, it enhances the coating’s weatherability and anti-aging properties in outdoor environments, reducing issues such as chalking and cracking.
3. Strengthening Adhesion and Mechanical Strength
The hydroxyl functional groups on its surface help improve adhesion to substrates. After surface modification, it bonds more tightly with the resin system, increasing tensile strength, impact resistance, and overall mechanical performance of the film.
4. Adjusting Rheological Properties of Coatings
It possesses a certain oil absorption value and thixotropic characteristics, which can increase viscosity, reduce pigment settling, and prevent sagging during application. Ultra-fine grades further improve dispersibility, shorten grinding time, and enhance storage stability and leveling properties.
5. Optical Adjustment and Cost Optimization
With relatively high whiteness and a refractive index close to that of certain resins, it can be used for matting, in transparent systems, or as an extender pigment. Without significantly affecting color performance, it can partially replace more expensive fillers, helping to reduce formulation costs.
6. Imparting Special Functions
Excellent electrical insulation, high-temperature resistance, and chemical corrosion resistance make it suitable for insulating coatings, high-temperature protective coatings, anti-corrosion coatings, and electronic potting materials that demand high functionality.
2. Typical Industry Application Scenarios
1. Epoxy Floor Coatings
Widely used in epoxy floors, abrasion-resistant floors, garage floors, and industrial plant floors. It improves coating hardness, abrasion resistance, and compressive strength while enhancing thickness and application stability. Spherical or quasi-spherical silica micro powder can also reduce viscosity and increase filler loading.
2. Anti-Corrosion Coatings
In steel structure anti-corrosion, chemical equipment, pipeline, and storage tank coatings, it enhances film denseness and improves resistance to acids, alkalis, salt spray, and media penetration.
3. Marine and Ship Coatings
Suitable for ship primers, deck paints, and offshore platform protective coatings. It helps improve weatherability, salt spray resistance, and abrasion resistance to withstand complex marine environments.
4. Electronic Potting and Insulating Coatings
In electronic potting compounds, insulating varnishes, and motor insulating coatings, it reduces curing shrinkage, enhances insulation performance and thermal stability, and improves dimensional stability.
5. Automotive Coatings
Used in automotive primers, intermediate coats, underbody protective coatings, and certain functional topcoats to improve abrasion resistance, stone-chip resistance, and mechanical strength.
6. Road Marking and Reflective Coatings
Improves abrasion resistance and weatherability, helping the coating maintain stability under vehicle traffic, UV exposure, and rain erosion.
7. Architectural and Industrial Protective Coatings
Applicable to exterior wall coatings, waterproof mortars, industrial floors, steel structure protection, and concrete protection systems. It provides filling, hardening, anti-cracking, and durability-enhancing effects.
8. Furniture Coatings and Powder Coatings
In wood coatings, furniture topcoats, and powder coatings, it adjusts gloss, improves surface feel, enhances abrasion resistance, and optimizes costs. In some formulations, it can partially replace titanium dioxide or barium sulfate.
The performance of quartz powder highly depends on particle size, dosage, resin system, and dispersion process:
– Particle Size Selection: Coarser grades are more effective for improving hardness and abrasion resistance; finer or ultra-fine grades are better for enhancing leveling, surface smoothness, and optical properties.
– Dosage: Should be verified through testing based on formulation viscosity, application method, and cost targets. Excessive addition may reduce flowability, cause film cracking, or create application difficulties. It is recommended to start testing from 5–20% or higher and adjust gradually.
– Surface Modification: For systems requiring high dispersibility, preferentially select silica micro powder treated with silane coupling agents or similar surface treatments. Combined with appropriate dispersants and grinding processes, this yields more stable performance and higher filler loading.
– Other Key Indicators: Whiteness, oil absorption, purity (Si O₂ content), and particle morphology (angular vs. quasi-spherical) all influence final film performance and cost.
Proper use of quartz powder (silica micro powder) can both enhance the overall performance of coatings and effectively control costs, making it a preferred functional filler. In practical applications, small-scale testing based on specific formulations is recommended to achieve optimal results.
